10pcs Plastic Reed Switch Reed Contact Normally Open (N/O) Magnetic Induction

10pcs Plastic Reed Switch Reed Contact Normally Open (N/O) Magnetic Induction

$10.51
  • Condition: New
  • Ships from: Tempe, US
  • Seller: drop_65 (99.8% positive)
View this item on eBay

SafeHouseHub is reader-supported. When you buy through links on this page we may earn an affiliate commission from eBay, at no additional cost to you. Read our affiliate disclosure.

About this item

Total Length 44mm Plastic Part Length 14mm Plastic Part Diameter 3mm Contact Form A Maximum power 10W Maximum switching voltage 100VDC Working temperature: -20 degrees to 80 degrees Maximum switching current 0.5A Maximum load current 1.0A Maximum contact resistance 100M Minimum insulation resistance 1010 Action time 1.0ms Bounce time 0.6ms Release Time 0.4ms Response frequency 4000Hz Maximum operating frequency 500Hz Sensitive Value 10-15AT Minimum reset Min Value 4FT Maximum contact capacitance 0.7PF Electrical life (load) 108 (5VDC, 10mA) 105 (24VDC, 400mA) Test line circle number / Resistance 870/5000Ω Package included:10 X Reed Switch
